Mounted drill Vega VS 20.6

Drilling CANIS a VEGA are next a new type of drilling machine HELTOS company, which is traditional producer bench and pillar drilling machines. Drilling machines of the range CANIS and VEGA are designed fro drilling, reaming and thread cutting in both single-part and series production.

Mentioned drilling machines have infinitely variable of revolutions, which is at type CANIS ensured by variator and by type VEGA by frequency converter. The headstock is solid complex, which ensure heavy duty frame and operational reliability.

Drilling depth is setting on millimeter scale. The spindle is seating in accurate ball bearings, spiral spring the spindle return in the upper position. The headstock and worktable are vertically adjustable and revolving 360°on the pillar. Electric equipment is concentrated in box on the side of the machine. By the help of contactor is drilling machine protected again spontaneous run-up after volts-drop. Both types are in bench design and pillar design.


Vega VS 20.6
Drilling diameter 600 Mpa mm 20
Drilling depth mm 160
Cone in MORSE spindle MORSE 3
Drilling depth indicator
Drilling depth backstop
precision setting
Clamping table area - horizontal mm 320 x 320
T - grooves
3 x w 14, spacing 80
Dist. from spindle end to clamp. table area max/min mm 840 / 0
Spindle reach mm 250
Diameter of column mm 120
Headstock vertical movement mm 200
Vertical movement of bracket with table mm 640
Vertical movement of table and headstock
geard rack
Spindle speed
continuous (converter)
- number of steps
- range r.p.m. 180 - 3700
Direction spindle speed
right - left
Primary transmission
by hand / mechanical
- range mm/r. -
Clutch type
Maximum axial pressure on spindle N 1100
Motor V 3 x 400
Electric motor speed/output r.p.m/kW 900 / 1,1
Coolant equipment
cont. 20 l, output 30 l/min
Maximum machine dimensions W x L x H mm 650 x 1130 x 2000
Machine weight (net/ gross) kg 340 / 410
Package (crating) dimensions W x L x H mm 690 x 1250 x 2150
